80 A Appendix
Installation Procedure
The ROM of the KR font kit goes into the controller
board right underneath an internal hard disk
(optional). If your printer has an internal hard disk,
remove it to get an access to the ROM slot. For
information on how to uninstall/re-install the
internal hard disk, refer to “ Installing the Internal
Hard Disk” (P. 74)
Follow these steps when installing the KR font
ROM to the printer:
1. Switch the power off by pressing the power
switch located on front lower right of the
printer to the <O> position.
Unplug the power cord from the power outlet
and the printer.
2. Remove the two screws that secure the rear
cover to the printer.
3. Pull the rear cover forward and remove it
from the printer.
4. Loosen the three screws that secure the
metal plate cover inside the printer.
5. Pull the metal plate cover forward and
remove it from the printer.
Font ROM
Internal hard disk
To Next Page
