Xerox Phaser 3320 User Manual

Parts Lists
Phaser 3320 and WorkCentre 3315/3325 Xerox Internal Use Only
Service Manual
5-20
30 LVPS Fan (110V printers only) 127N07782
31 Exhaust Fan
32 Sensor Harness
33 Clutch Motor Harness
34 Air Temp Harness
35 Exit Harness
36 Rear Cover & Bin Full Sensor Harness
37 HVPS Harness
38 LVPS (Signal) Harness
39 Flat Cable
40 Therm Fuser Harness
41 Power LVPS Harness
42 Inlet-2 AC Harness
43 Bias Fuser Harness
44 HVPS 105N02248
45 Electric Clutch (Registration Clutch) 121N01219
46 Electric Clutch (Pick Up Clutch) 121N01220
47 TR(KOR) ETC Spring
48 4 Bush
49 Idle Feed M Bush
50 L TR M Bush
51 SAW P Plate
52 Bushing Push P Plate
53 4PI Ring M E Fixer
54 Swing Collar
55 Swing Bracket
56 Regi
57 Transfer Earth Plate
58 TR L Bush
59 Path EX Duplex Frame
60 Exit Shaft Bush
61 Base Frame
62 Ground Paper Bracket
63 LSU Bracket
64 Duplex Frame Guide
65 Exit Sensor and Holder (not part of Fuser) 130N01669
Item Name Part Number
www MK-Electronic de

Xerox Phaser 3320 Specifications

General

Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	220 - 240 V
Power consumption (standby)	48 W
Power consumption (printing)	420 W
Power consumption (PowerSave)	10 W
PCL fonts	112
Certification	FCC Part 15, Class B, FCC Part 68, CE Mark applicable to Low Voltage Directive 2006/95/EC, EMC Directive 2004/108/EC and R&TTE Directive 1999/5/EC, UL 60950-1/CSA 60950-1-07, 2nd Edition, GOST, NOM, GS Mark, Citrix Ready, Section 508 (compliant with minor exceptions)
Product color	Beige, Navy
Country of origin	China
Maximum duty cycle	80000 pages per month
Recommended duty cycle	1 - 6000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	820 sheets
Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	37 ppm
Maximum internal memory	384 MB
Package weight	11.7 kg
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Network ready	-
Security algorithms	HTTPS
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	507.99 mm
Width	444.49 mm
Height	355.59 mm
