Parts List 3.2 Bypass Tray
Item Name Part Number
0 Bypass Tray 130N01676
1 Taptype Screw
2 Idle Holder MP
3 Roller Cover
4 Idle Roller
5 ETC Pin
6 CS Spring
7 Lower MP
8 Empty MP Actuator
9 Lower MP Guide
10 Bypass Tray Paper Empty Sensor 130N01574
11 Cassette Pad RPR
12 TS Spring
13 CS Spring
14 Retard Roller Cassette (Retard Roller) (includes 15, 16) 022N02677
15 Torque Limiter Coupler
16 TL Rubber
17 Retard Shaft Holder 006N01347
18 Upper MP
19 Arm MP Actuator
20 Upper MP Guide
21 Bush PMO
22 MP Stopper
23 ES Spring
24 Pick Up MP (Bypass Tray Pick Up Assembly) 130N01675
25 MP Collar
26 Idle Pick Up Gear
27 Joint Gear
28 Joint2 MP Gear
29 Shaft Holder
30 Pick Up MP Housing
31 Pick Up Clutch Sub PMO
32 Pick Up Rubber
33 Pick Up Sub Shaft
34 Pick Up MP Shaft
35 MP Clutch Sleeve
36 MP Sleeve
37 TS Spring
38 Plain Washer
www MK-Electronic de

Xerox Phaser 3320 Specifications

General

Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	220 - 240 V
Power consumption (standby)	48 W
Power consumption (printing)	420 W
Power consumption (PowerSave)	10 W
PCL fonts	112
Certification	FCC Part 15, Class B, FCC Part 68, CE Mark applicable to Low Voltage Directive 2006/95/EC, EMC Directive 2004/108/EC and R&TTE Directive 1999/5/EC, UL 60950-1/CSA 60950-1-07, 2nd Edition, GOST, NOM, GS Mark, Citrix Ready, Section 508 (compliant with minor exceptions)
Product color	Beige, Navy
Country of origin	China
Maximum duty cycle	80000 pages per month
Recommended duty cycle	1 - 6000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	820 sheets
Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	37 ppm
Maximum internal memory	384 MB
Package weight	11.7 kg
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Network ready	-
Security algorithms	HTTPS
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	507.99 mm
Width	444.49 mm
Height	355.59 mm
