Xerox Phaser 3320 User Manual

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-27
Parts List 3.3 Fuser
Item Name Part Number
0 110V Fuser
220V Fuser
126N00410
126N00411
2 NTC Assy Thermistor 130N01668
3 Thermostat
4 Halogen Lamp (110V/220V)
5 Taptype Screw
6 Taptype Screw
7 Taptype Screw
8 E Ring
9 E Ring
10 ETC Spring
11 CS Spring
12 CS Spring
13 ETC Spring
14 ETC Spring
15 Ball Bearing
16 Joint Fuser Harness
17 Con Fuser Harness
18 PR 1st Bush
19 Claw Guide
20 Ground PR Guide
21 Jam Holder
22 Fuser Frame
23 HR Bush
24 2nd PR Bush
25 Input Guide
26 Bearing Bracket
27 Gear Bracket
28 PR M Ground
29 Fuser Cover
30 Idle Roller
31 Pressure Roller
32 2nd Pressure Roller
33 Fuser Gear
34 Exit Idle Gear
35 L Jam Link Lever
36 R Jam Link Lever
37 Exit Idle Roller
38 Heat Roller
39 L Lamp Cap
40 R Lamp Cap
41 Caution Label
42 F/UP Idle Shaft IEX
www MK-Electronic de

Xerox Phaser 3320 Specifications

General

Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	220 - 240 V
Power consumption (standby)	48 W
Power consumption (printing)	420 W
Power consumption (PowerSave)	10 W
PCL fonts	112
Certification	FCC Part 15, Class B, FCC Part 68, CE Mark applicable to Low Voltage Directive 2006/95/EC, EMC Directive 2004/108/EC and R&TTE Directive 1999/5/EC, UL 60950-1/CSA 60950-1-07, 2nd Edition, GOST, NOM, GS Mark, Citrix Ready, Section 508 (compliant with minor exceptions)
Product color	Beige, Navy
Country of origin	China
Maximum duty cycle	80000 pages per month
Recommended duty cycle	1 - 6000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	820 sheets
Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	37 ppm
Maximum internal memory	384 MB
Package weight	11.7 kg
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Network ready	-
Security algorithms	HTTPS
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	507.99 mm
Width	444.49 mm
Height	355.59 mm
