Xerox Phaser 3320 User Manual

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-45
Parts List 8.1 WorkCentre 3325 DADF Platen
Item Name Part Number
0 DADF 022N02682
2 Platen DADF
3 Lower DADF
4 Upper DADF
5 DADF Drive 007N01712
6 GND1 CBF Harness
7 Zener GND CBF Harness
8 DADF PBA (DADF Board) 140N63301
9 DADF Harness
10 DADF Rear Cover
11 DADF Front Cover
12 DADF Open Cover 002N03064
12.2 DADF Up Pick MEA Unit (Sep Pad see PL#8.3) 130N01533
12.3 Bush PMO
12.4 Taptype Screw
12.5 Stopper MEA Unit
12.6 Open Cover
12.7 Sensor M DOC Guide
12.8 Pick Up Spring ETC
12.9 Upper DADF Damper
13 DADF Stacker
14 DADF Hinge MEA Unit 003N01083
15 Hinge Unit MEA 003N01051
16 Taptype Screw
17 Machine Screw
www MK-Electronic de

Xerox Phaser 3320 Specifications

General

Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	220 - 240 V
Power consumption (standby)	48 W
Power consumption (printing)	420 W
Power consumption (PowerSave)	10 W
PCL fonts	112
Certification	FCC Part 15, Class B, FCC Part 68, CE Mark applicable to Low Voltage Directive 2006/95/EC, EMC Directive 2004/108/EC and R&TTE Directive 1999/5/EC, UL 60950-1/CSA 60950-1-07, 2nd Edition, GOST, NOM, GS Mark, Citrix Ready, Section 508 (compliant with minor exceptions)
Product color	Beige, Navy
Country of origin	China
Maximum duty cycle	80000 pages per month
Recommended duty cycle	1 - 6000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	820 sheets
Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	37 ppm
Maximum internal memory	384 MB
Package weight	11.7 kg
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Network ready	-
Security algorithms	HTTPS
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	507.99 mm
Width	444.49 mm
Height	355.59 mm
