Xerox Phaser 3320 User Manual

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-61
Parts List 11.1 WorkCentre 3315/3325 Middle Platen
Item Name Part Number
0 Middle Platen 3315
Middle Platen 3325
090N00172
090N00177
1 Scan Drive ELA Unit (Scan Motor) 007N01629
2 M Idle Pulley
3 Pulley Scan Bracket
4 Flat Cable
5 Belt P Clip
6 CS Spring
7 CS Spring
8 Taptype Screw
9 Home Position Sensor 130N01601
10 Contact Image Sensor (WorkCentre 3315)
Contact Image Sensor (WorkCentre 3325)
130N01667
130N01679
11 CIS Guide
12 Home Scan Harness
13 Scan Shaft
14 Lower Scan Frame
15 CIS Bracket
16 Gear Timing Belt 007N01704
17 FFC Cover
www MK-Electronic de

Xerox Phaser 3320 Specifications

General

Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	220 - 240 V
Power consumption (standby)	48 W
Power consumption (printing)	420 W
Power consumption (PowerSave)	10 W
PCL fonts	112
Certification	FCC Part 15, Class B, FCC Part 68, CE Mark applicable to Low Voltage Directive 2006/95/EC, EMC Directive 2004/108/EC and R&TTE Directive 1999/5/EC, UL 60950-1/CSA 60950-1-07, 2nd Edition, GOST, NOM, GS Mark, Citrix Ready, Section 508 (compliant with minor exceptions)
Product color	Beige, Navy
Country of origin	China
Maximum duty cycle	80000 pages per month
Recommended duty cycle	1 - 6000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	820 sheets
Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	37 ppm
Maximum internal memory	384 MB
Package weight	11.7 kg
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Network ready	-
Security algorithms	HTTPS
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	507.99 mm
Width	444.49 mm
Height	355.59 mm
