Xerox Phaser 3320 User Manual

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-63
Parts List 12.1 Optional Cassette Tray 2
Item Name Part Number
0 Optional Tray'URS6KLSWR&XVWRPHU1RW6HUYLFH3DUW1
1 Bottom Frame
2 Roller CST Holder
3 F/UP Idle Shaft IEX
4 Bottom CST Roller
5 Right Frame ELA Unit
6 Left Frame ELA Unit
7 Pick Up Unit A/S Assy 130N01674
8 D6/L4 Bush
9 E Ring
10 Up Pick Drv Gear
11 Regi Roller SCF CSP
12 8/5 Bush
13 E (ID5) Ring
14 Feed Unit Con A/S
15 Tapping Screw (M3XL8)
16 Drive Unit A/S Assy 007N01666
17 Hex Screw (M3XL6)
18 Electric Clutch 121N01219
19 Regi (M) Clutch Brkt SCF CSP
20 D6/L4 Bush
21 Electric Clutch 121N01220
22 Cable Clamp
23 Main SCF PBA A/S Assy (Optional Tray Feeder Board) 140N63640
24 Top Frame
25 Taptype Screw (M3XL6)
26 ES Spring
27 Dummy Right MEA Unit
28 Tapping Screw (M3XL8)
29 Dummy Rear Cover
30 Cassette Cover
31 Left Cover CSP 002N03061
32 Right Cover CSP 002N03062
33 Top Dummy Cover CSP 002N03060
34 Front Dummy Cover CSP 002N03063
35 Cassette A/S Assy 050N00647
36 AS Unit Lift 120N00537
37 Unit Pick up Roller 022N02232
38 Option Tray Harness 152N11847
www MK-Electronic de

Xerox Phaser 3320 Specifications

General

Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	220 - 240 V
Power consumption (standby)	48 W
Power consumption (printing)	420 W
Power consumption (PowerSave)	10 W
PCL fonts	112
Certification	FCC Part 15, Class B, FCC Part 68, CE Mark applicable to Low Voltage Directive 2006/95/EC, EMC Directive 2004/108/EC and R&TTE Directive 1999/5/EC, UL 60950-1/CSA 60950-1-07, 2nd Edition, GOST, NOM, GS Mark, Citrix Ready, Section 508 (compliant with minor exceptions)
Product color	Beige, Navy
Country of origin	China
Maximum duty cycle	80000 pages per month
Recommended duty cycle	1 - 6000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	820 sheets
Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	37 ppm
Maximum internal memory	384 MB
Package weight	11.7 kg
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Network ready	-
Security algorithms	HTTPS
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	507.99 mm
Width	444.49 mm
Height	355.59 mm
