Printing Special Job Types
Phaser® 8560/8860 Printer
1-23
Sending Print With Jobs
To select jobs to send with your current job in a supported driver:
Note: Print With jobs are not available for AppleTalk or USB connected printers.
Operating System Steps
Windows 2000 or later 1. Select the Paper/Output tab.
2. Select Print With under Job Type.
3. In the Print With dialog box, select a personal saved or shared
saved job from the list on the left to be printed with the current job,
and then click the Add button to add it to the Final Job list on the
right.
4. To change the order of the jobs to be printed, select a job to be
moved in the list on the right, and then click the Move Up or Move
Down button.
5. Click the OK button.
Mac OS X (version
10.3 and higher) driver
1. In the Print dialog box, select Print With from the Job Types
drop-down list.
2. Enter a four digit number, ranging from 0000 through 9999, in the
Numeric Password field and click the Set button.
3. Select a personal saved or shared saved job from the list on the left
to be printed with the current job, and then click the Move Right
button.
4. To change the order of the jobs to be printed, select a job to be
moved in the list on the right, and then click the Move Up or Move
Down button.

Table of Contents

Other manuals for Xerox Phaser 8560

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox Phaser 8560 and is the answer not in the manual?

Xerox Phaser 8560 Specifications

General IconGeneral
ColorYes
Duplex printingNo
Print technologyLaser
Maximum resolution2400 x 600 DPI
Time to first page (color, normal)5 s
Print speed (black, normal quality, A4/US Letter)3 ppm
Print speed (color, normal quality, A4/US Letter)30 ppm
Maximum internal memory1 MB
Sound power level (standby)33 dB
Sound pressure level (printing)54 dB
Maximum duty cycle85000 pages per month
Number of print cartridges4
Page description languagesPCL 5c
Maximum input capacity625 sheets
Paper tray 2 input capacity525 sheets
Multi-Purpose tray input capacity100 sheets
Power requirements110 - 240 V, 50/60 Hz
Networking features10/100BaseTX
Standard media sizes140 x 216 mm - 216 x 356 mm
Power consumption (active)230 W
Compatible operating systemsLinux, Mac OS X 10.2 +, Novell NetWare 3.x +, Windows 2000 +
Envelopes sizesC5, DL
Maximum print size216 x 356 mm
Paper tray media typesBond paper, Envelopes, Glossy paper, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizesExecutive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Supported network protocols (IPv4)IPv6
Sustainability certificatesENERGY STAR
Power consumption (PowerSave)43 W
Storage temperature (T-T)-30 - 60 °C
Operating temperature (T-T)10 - 32 °C
Storage relative humidity (H-H)10 - 95 %
Operating relative humidity (H-H)10 - 80 %
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)406 x 533.4 x 368 mm
