Xerox Phaser 8560 Advanced Features Guide

Macintosh
Phaser® 8560/8860 Printer
3-12
Enabling or Using TCP/IP or AppleTalk for Mac OS X, Version
10.3 and Higher
Verify that you are running Mac OS X, version 10.3 or higher. The previous versions of
Mac OS X do not fully support PostScript printing and printer features.
Setting Up the Macintosh Ethernet Port for TCP/IP
To set up your Macintosh for TCP/IP:
1. Select Network from the System Preferences application.
2. Select Built-In Ethernet from the Show menu.
3. Specify how you will obtain the IP address from the TCP/IP tab:
■ Manually: Specify the IP address, Subnet Mask, Router Address, and Name Server
Address in the dialog box.
■ Using DHCP: Automatically finds the IP address.
4. Click Apply, and then close the dialog box.
See also:
Online Support Assistant at www.xerox.com/office/8560Psupport
or www.xerox.com/
office/8860support
Setting Up the Macintosh Ethernet Port for AppleTalk
To set up your Macintosh for AppleTalk:
1. Select Network from the System Preferences application.
2. Select Built-In Ethernet from the Show menu.
3. Select Make AppleTalk Active in the AppleTalk tab.
4. Click Apply, and then close the dialog box.
Creating an LPR Printer with Mac OS X, Version 10.3 and Higher
To create an LPR printer:
1. Open the Print Center utility. In Mac OS X, version 10.3 or higher, open the Printer
Setup Utility. The utility is located in a directory called Utilities in the Applications
directory.
2. Select Add, then select LPD/LPR in the Printer Type field.
3. Enter the printer’s IP address in the Printer Address field.
4. Select the appropriate PPD from the list in the Printer Model pull-down list. If your
printer PPD is not listed, install it from the Software and Documentation CD-ROM.
5. Click Add to complete the configuration.

Xerox Phaser 8560 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (color, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	3 ppm
Print speed (color, normal quality, A4/US Letter)	30 ppm
Maximum internal memory	1 MB
Sound power level (standby)	33 dB
Sound pressure level (printing)	54 dB
Maximum duty cycle	85000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c
Maximum input capacity	625 sheets
Paper tray 2 input capacity	525 sheets
Multi-Purpose tray input capacity	100 sheets
Power requirements	110 - 240 V, 50/60 Hz
Networking features	10/100BaseTX
Standard media sizes	140 x 216 mm - 216 x 356 mm
Power consumption (active)	230 W
Compatible operating systems	Linux, Mac OS X 10.2 +, Novell NetWare 3.x +, Windows 2000 +
Envelopes sizes	C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Glossy paper, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	IPv6
Sustainability certificates	ENERGY STAR
Power consumption (PowerSave)	43 W
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	406 x 533.4 x 368 mm
