Xerox WorkCentre 5875 Quick Guide

1
Services Home
2
Job Status
3
Touch Screen
4
Start
5
Clear All
6
Stop
1
2
3
4
5
6
Control panel
OR
Document feeder option
Document glass option
How to Send an E-mail
Load your documents face up in the document feeder input tray. Adjust the guide to just touch the documents1. OR lift up the document
feeder. Place the document face down onto the document glass and register it to the arrow at the top left corner. Close the document feeder.
Press the 2. Clear All (AC) button to cancel any previous screen programing selections.
Press the3.
Services Home button on the Control Panel.
Select the 4.
E-mail button on the touch screen.
If required, select the 5. E-mail tab. This is usually the active tab when the E-mail service opens.
Select the 6.
New Recipient... button.
Use the touch screen keyboard to enter the recipient’s e-mail address.7.
Select the 8.
Add button.
Select the 9. Close button to save the information you entered.
Select any options required.10.
Press the 11.
Start button on the Control Panel to scan the original.
For more information
Please refer to: user guides - available
via
http://www.support.xerox.com
©2012 Xerox Corporation. All rights reserved. XEROX®, XEROX and Design® are trademarks of Xerox Corporation in the U.S. and/or other countries.
IG120003
Xerox
®
WorkCentre™ 5845/5855/5865/5875/5890

Xerox WorkCentre 5875 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	300, 000 pages
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Memory (Standard)	2 GB
Hard Drive	160 GB
Print Speed (Black)	75 pages per minute
Maximum Paper Capacity	4, 700 sheets
Scan Speed (Black)	200 images per minute
Scan Speed (Color)	200 images per minute
Connectivity	USB 2.0, 10/100/1000Base-T Ethernet
Control Panel	Touchscreen
Processor	1.2 GHz
Operating System Compatibility	Windows, Mac, Linux
