8-6
Exploded View & Parts List
Service Manual
Frame Unit Assembly Parts List(Cont.)
SA : Service Available
O : Service available X : Service not available
No. Description SEC.Code Q’ty SA Remark
39 IPR-P-GROUND_FUSER JC70-00310A 1 X
40 SHAFT-FEED IDLE JC66-00527A 1 X
41 BUSH-M-FEED IDLE JC61-00585A 2 X
42 SPRING ETC-TR JC61-70958A 2 X Spring Feed Idle
43 IPR-P_GROUND_DRIVE2 JC70-00335A 1 X
44 SPRING-TS 6107-001170 1 X Spring-cam Pick-up
45 CAM-M-PICK_UP JC66-00377A 1 O
46 IPR-P-GROUND_DRIVE JC70-00308A 1 X
47 SOLENOID-HB (PICK-UP) JC33-00009A 1 O
48 SOLENOID-HB (MANUAL) JC33-00010A 1 O
49 AS-GEAR PICK_UP JC81-01692A 1 O
49-1 PMO-GEAR PICK_UP B JC72-00980A 1 X
49-2 PMO-GEAR PICK_UP A JC72-00979A 1 X
49-3 SPRING-CS 6107-001167 1 X Spring-Pick-up gear
50 BRACKET-P-FEED JC61-00602A 1 O
51 IPR-P-GROUND_TR JC70-00311A 1 X
52 SHAFT-FEED JC66-00398A 2 X
53 RING-CS 6044-000001 3 X
54 GEAR-FEED 2 JC66-00394A 1 X
55 GEAR-IDLE 23 JC66-00396A 1 X
56 GUIDE-P-PAPER JC61-00718A 1 X
57 FOOT-FRONT JC61-00836A 2 X
58 AS-PICK UP JC81-01693A 1 O
58-1 BUSH-M-PICK_UP L JC61-00586A 1 X
58-2 SHAFT-P-PICK_UP JC66-00399A 1 X
58-3 STOPPER-PICK_UP JC61-00593A 2 X
58-4 PMO-IDLE PICK_UP JC72-00982A 2 X
58-5 SPONGE-ROLLER PICK_UP JC72-01231A 1 X
58-6 BUSH-M-PICK_UP R JC61-00587A 1 X
58-7 HOUSING-M-PICK_UP JC61-00591A 1 X
59 MEA UNIT-CLUTCH JC97-01788A 1 O
59-1 GEAR-FEED 1 JC66-00393A 1 X
59-2 PMO-COLLAR_SPRING JC72-00978A 1 X
59-3 SPRING-TS 6107-001171 1 X
59-4 PMO-HUB CLUTCH JC72-00981A 1 X
60 ELA HOU-FUSER_220V JC96-03135B 1 O 220V
ELA HOU-FUSER_110V JC96-03135A 1 O 110V
61 RMO-RUBBER EXIT JC73-40915A 4 X
62 PBA MAIN-PTL JC92-01620B 1 O
63 IPR-GROUND_SAW JC63-00465A 1 X
To Next Page
