8-5
Exploded View & Parts List
Service Manual
Frame Unit Assembly Parts List
SA : Service Available
O : Service available X : Service not available
No. Description SEC.Code Q’ty SA Remark
0 ELA UNIT-FRAME LOWER, 110V JC96-03137A 1 O 110V
ELA UNIT-FRAME LOWER, 220V JC96-03137B 1 O 220V
1 FRAME-M-BASE JC61-00579A 1 X
2 GUIDE-P-PAPER JC61-00943A 1 O
3 PLATE-P-SAW JC61-00604A 1 O
4 GUIDE-M-TR RIB JC61-00933A 1 O
5 GEAR-EXIT F/DOWN JC66-00038A 1 X
6 HOLDER BEARING EXIT F/DOWN JC61-00829A 2 X
7 ROLLER-EXIT F/DOWN JC66-00378A 1 O
8 SPRING-CS 6107-001163 4 O Spring Exit
9 PMO-GEAR_EXIT_DRV16 JC72-00143A 2 X
10 HOLDER-M-EXIT F/DOWN JC61-00582A 4 O
11 PMO-ROLLER_EXIT,MAIN JC72-41081B 4 X
12 PMO-ROLLER_EXIT,FR JC72-41082B 4 X
13 MEC-TERMINAL JC75-00049A 4 O
14 IPR-P-TERMINAL CON JC70-00312A 3 X
15 IPR-P-TERMINAL CR JC70-00313A 1 X
16 HOUSING-TERMINAL JC61-00592A 1 O
17 PMO-LOCKER CST JC72-00983A 2 O
18 PMO-ACTUATOR CVR OPEN JC72-00974A 1 O
19 PMO-PLATE GUIDE DEVE_R JC72-00985A 1 O
20 SPRING ETC-GUIDE DEVE JC61-70932A 2 X
21 IPR-P-GROUND_GUIDE PAPER JC70-00458A 1 X
22 PMO-PLATE GUIDE DEVE_L JC72-00984A 1 O
23 PMO-ACTUATOR FEED JC72-00976A 1 O
24 PMO-ACTUATOR EMPTY JC72-00975A 1 O
25 PMO-ACTUATOR MANUAL JC72-00977A 1 O
26 IPR-P-GROUND_EARTH TR JC70-00309A 1 X
27 SPRING-ETC 6107-001162 1 X
28 ROLLER-FEED ROLLER 1 JC66-00526A 1 O
29 PMO-BUSHING FEED JC72-00382B 4 O
30 ROLLER-FEED JC66-00598A 1 O
31 SPRING-TS 6107-001165 1 X Spring-act,Manual
32 IPR-P-EARTH TRANSFER JC70-00307A 1 O
33 HOLDER-PTL JC61-00583A 1 X
34 LENS-PTL JC67-00027A 1 O
35 BUSH-M-TR L JC61-00588A 1 X
36 SPRING ETC-TR L HAWK JC61-00047A 1 X
37 SPRING-TS 6107-001165 1 X Spring-act,Feed
38 PMO-BUSHING_TR(L) JC72-00102A 1 X
