8-13
Exploded View & Parts List
Service Manual
Middle Cover Unit Assembly Parts List
SA : Service Available
O : Service available X : Service not available
No. Description SEC.Code Q’ty SA Remark
0 MEA UNIT-COVER MIDDLE JC97-01958E 1 O
1 COVER-M_MIDDLE JC63-00473E 1 O
2 PMO-STACKER JC72-01340B 1 O
3 STOPPER-M-LEVER JC61-00949A 1 X
4 SPRING ETC-TS-CHARGE APOLLO JC61-00026A 1 X
5 PMO-SUB_M_STACKER JC72-01343A 2 X
6 PMO-BUSHING_F/DOWN JC72-00387A 1 X
7 WINDOW-M LCD JC64-00153B 1 O
8 KEY-M_START JC64-00151B 1 O
9 KEY-M_STOP JC64-00150B 1 O
10 KEY-M_MENU JC64-00152B 1 O
11 PBA SUB-PANEL JC92-01586A 1 O
12 COVER-M-PANEL JC63-00474A 1 O
13 SHEET-LCD JC63-00542A 1 O
To Next Page
