Xiaomi Robot Vacuum E10 User Manual

11
Remove the mop pad from the mop pad holder. Wash it and let it air dry.
Mop Pad Brush and Side Brush
Cleaning the Brush
Cut the hair Remove dirt and debris
It is recommended to clean sensors and charging contacts every three months
with a so cloth.
Sensors and Charging Contacts
Cliff Sensor
Charging Contacts
Collision Sensor
Infrared Obstacle Sensor
Edge Sensor
Š š
Ţ
ş
1. Remove the side brush.
2. Remove the brush cover, take out the brush, and pull out the brush bearing.
3. Use the cleaning brush to clean.
Brush Cover
Brush
Brush Bearing
Side Brush

Xiaomi Robot Vacuum E10 Specifications

General

Suction Power	4000 Pa
Battery Capacity	2600 mAh
Dustbin Capacity	400 ml
Dimensions	325 x 325 x 80 mm
Noise Level	65 dB
Compatible Floor Types	Hardwood, Tile, Carpet
Runtime	110 minutes
Charging Time	4 hours
Connectivity	Wi-Fi
Control	App, Voice
Water Tank Capacity	200 ml
