For each card in the server, you will see an output similar to the following example.
Card [0000:65:00.0]
Card type: u250
Flash type: SPI
Flashable partition running on FPGA:
xilinx_u250_gen3x16_base_3,[ID=0x48810c9d17860ef5],[SC=4.6.6]
Flashable partitions installed in system:
xilinx_u250_gen3x16_base_3,[ID=0x48810c9d17860ef5],[SC=4.6.6]
The name of the base paron, ID, and SC rmware version running on the FPGA are found
under Flashable partition running on FPGA while the ones installed in the system
are found under Flashable partitions installed in system.
In this example, the BDF is 0000:65:00.0, the base paron on the FPGA and system are
idencal (xilinx_u250_gen3x16_base_3), the ID is 0x48810c9d17860ef5 and the SC
version is 4.6.6.
2. Conrm the base paron under Flashable partition running on FPGA is idencal
to the that under Flashable partitions installed in system.
If these versions do not match, perform a cold reboot, and retry.
Running xbmgmt partition
The xbmgmt partition command for Dynamic Funcon eXchange plaorms supporng two
recongurable parons (DFX-2RP) provides opons to display the base and shell rmware
versions running on the card, as well as program the shell rmware.
1. Display the base rmware running on the card by entering the following command.
$ sudo /opt/xilinx/xrt/bin/xbmgmt partition --scan
For each card in the server, you will see an output similar to the following example.
Card [0000:65:00.0]
Partitions running on FPGA:
xilinx_u250_gen3x16_base_3
logic-uuid:
48810c9d17860ef53e9e529e8b14ce39
interface-uuid:
695718ec21a232e45e1afcb4e558e11f
Partitions installed in system:
xilinx_u250_gen3x16_xdma_shell_3_1
logic-uuid:
bd5fb8abab266c3265918257b5048e88
interface-uuid:
f2f6c5e1273e78948f2c4806221462f2
Chapter 5: Card Bring-Up and Validation
UG1301 (v1.8) February 5, 2021 www.xilinx.com
Getting Started with Alveo Accelerator Cards 31
