Under Partitions running on FPGA it displays the base paron running on the FPGA
xilinx_u250_gen3x16_base_3. A shell paron will also be displayed if it has already
been programmed.
Under Partitions installed in system it displays available shell paron(s)
available to program on the FPGA. In this example, only one shell paron is available
xilinx_u250_gen3x16_xdma_shell_3_1.
The logic-uuid and interface-uuid are used by the system to ensure compable base
and shell parons are used for a given applicaon.
If no shell parons are displayed under Partitions installed in system, it implies
no shell parons compable with the base paron have been installed. Download and
install a compable shell paron.
2. Enter the following command to program the shell paron on the FPGA.
$ sudo /opt/xilinx/xrt/bin/xbmgmt partition --program --name
<shell_name> --card <card_bdf>
where <shell_name> is the name of the shell paron to be programmed to the card
idened with BDF <card_bdf>.
In the previous example xilinx_u250_gen3x16_xdma_shell_3_1 will be programmed
to card with BDF 00:65:00.0. See Appendix D: Obtaining xbmgmt Command Opons to
obtain the card_bdf and shell_name opon.
An output similar to the following example will be displayed:
Programming PLP on Card [0000:65:00.0]...
Partition file: /opt/xilinx/firmware/u250/gen3x16/xdma-shell/
partition.xsabin
Program successfully
3. Enter the following command and conrm the shell paron displayed under Partitions
installed in the system and Partitions running on FPGA match.
$ sudo /opt/xilinx/xrt/bin/xbmgmt partition --scan
An output similar to the following example will be displayed.
Card [0000:65:00.0]
Partitions running on FPGA:
xilinx_u250_gen3x16_base_3
logic-uuid:
48810c9d17860ef53e9e529e8b14ce39
interface-uuid:
695718ec21a232e45e1afcb4e558e11f
xilinx_u250_gen3x16_xdma_shell_3_1
logic-uuid:
bd5fb8abab266c3265918257b5048e88
interface-uuid:
f2f6c5e1273e78948f2c4806221462f2
Partitions installed in system:
Chapter 5: Card Bring-Up and Validation
UG1301 (v1.8) February 5, 2021 www.xilinx.com
Getting Started with Alveo Accelerator Cards 32
