Xilinx Alveo U200 User Manual

Card Features
Features of the producon Alveo U200/U250/U280 data center accelerator cards are listed in
the following table.
Table 1: Alveo U200/U250/U280 Features
Card Component U200 U250 U280
FPGA UltraScale+
XCU200-2FSGD2104E
UltraScale+
XCU250-2LFIGD2104E
UltraScale+
XCU280-L2FSVH2892E
DDR4 64 gigabyte (GB)
4x DDR4 16 GB
32 gigabyte (GB)
2x DDR4 16 GB
2400 mega-transfers per second (MT/s), on 64-bit ECC DIMM
HBM – – 8 GB, 32-pseudo channels
Configuration Options 1 gigabit (Gb) Quad Serial Peripheral Interface (SPI) flash memory
Micro-USB JTAG configuration port
PCIe 16-lane PCI Express
PCIe Integrated Endpoint block connectivity
Gen1, 2, or 3 up to x16 Gen1, 2, or 3 up to x16
Gen4 x8
Network Interface 2x QSFP28 2x QSFP28 2x QSFP28
I2C Bus ✓ ✓ ✓
Status LEDs ✓ ✓ ✓
Power Management Power management with system management bus (SMBus) voltage, current, and
temperature monitoring
Electrical Design Power 65W PCIe slot functional with PCIe slot power only
140W PCIe slot functional with 110A max V
CCINT
current PCIe slot power and 6-pin PCIe AUX
power cable connected
215W PCIe slot functional with 160A max V
CCINT
current PCIe slot power and 8-pin PCIe AUX
power cable connected
1
Flash Memory Onboard reprogrammable flash configuration memory
UART UART access through the USB port
Configuration UltraScale+ device configurable over USB/JTAG and Quad SPI configuration flash memory
Notes:
1. Vitis unified software platform based applications are only designed to run with electrical design power at 215W.
Minimum System Requirements
The minimum system requirements for running the Alveo™ U200/U250/U280 Data Center
accelerator cards are listed in the following table.
Chapter 1: Introduction
UG1301 (v1.8) February 5, 2021 www.xilinx.com
Getting Started with Alveo Accelerator Cards 8
Send Feedback
