GTP Transceiver Model Correlation
Note: The blue waveforms cannot be seen because the red waveforms are covering them.
X-Ref Target - Figure B-10
Figure B-10: TXDIFFCTRL = 1010, TXPREEMP = 000, RXEQMIX = 01 (Typical - GTP Transceiver)
UG396_aB_10_051410
02
Eldo
FOM=99.8846%
HSPICE
145
Time (ns)
Volts
(Vppd)
63
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
02
Eldo
FOM=99.8344%
HSPICE
145
Time (ns)
Volts
(Vppd)
63
-0.8
-0.6
-0.4
-0.2
0.2
0
0.4
0.8
0.6
Typical, TXDIFFCTRL=1010, TXPREEMPHASIS=000, RXEQMIX=01 − MGTTX
Typical, TXDIFFCTRL=1010, TXPREEMPHASIS=000, RXEQMIX=01 − MGTRXOUT
