Xilinx Spartan-6 User Manual

6 www.xilinx.com Spartan-6 FPGA GTP Transceiver SIS Kit (HyperLynx)
UG396 (v1.0) June 10, 2010
Preface: About This Guide
Online Document
The following conventions are used in this document:
Italic font
References to other documents
See the Spartan-6 FPGA
Configuration Guide for more
information.
Emphasis in text
The address (F) is asserted after
clock event 2.
Square brackets [ ]
An optional entry or parameter.
However, in bus specifications,
such as bus[7:0], they are
required.
ngdbuild [option_name]
design_name
Convention Meaning or Use Example
Convention Meaning or Use Example
Blue text
Cross-reference link to a location
in the current document
See the section Additional
Support Resources for details.
Refer to Overview, page 7 for
details.
Blue, underlined text
Hyperlink to a website (URL)
Go to http://www.xilinx.com
for the latest documentation.

Xilinx Spartan-6 Specifications

General

Maximum Transceiver Data Rate	3.2 Gbps
Number of Transceivers	Up to 8
Supported Protocols	Ethernet
Power Supply	1.0V, 2.5V, 3.3V
Operating Temperature	0°C to +85°C (Commercial), -40°C to +100°C (Industrial)
Transceiver Type	Multi-Gigabit Transceivers (MGTs)
