Xilinx Spartan-6 User Manual

Spartan-6 FPGA GTP Transceiver SIS Kit (HyperLynx) www.xilinx.com 17
UG396 (v1.0) June 10, 2010
Appendix A
Frequently Asked Questions
All Versions
1. What does the “Device-kit .INI file where_am_i\S6_kit.ini does not exist or could not
be read” message shown in Figure A-1 mean?
HyperLynx cannot find the Device-kit.INI file, most likely because the
DesignName.pjh file has an incorrect path for the INI file. The S6_kit.ini file is
located in the hl_projects directory. Either:
•Click No, close HyperLynx, edit the PJH file as described in Installation and
Requirements, page 7, and start HyperLynx again,
or
•Click Yes and browse to the hl_projects directory to locate the
DesignName.pjh file.
X-Ref Target - Figure A-1
Figure A-1: Device-kit .INI Error Message
UG396_aA_01_042010

Xilinx Spartan-6 Specifications

General

Maximum Transceiver Data Rate	3.2 Gbps
Number of Transceivers	Up to 8
Supported Protocols	Ethernet
Power Supply	1.0V, 2.5V, 3.3V
Operating Temperature	0°C to +85°C (Commercial), -40°C to +100°C (Industrial)
Transceiver Type	Multi-Gigabit Transceivers (MGTs)
