Xilinx ZCU102 Manual

© Copyright 2016 Xilinx
.
The Maxim PowerTool software used in this presentation can
adjust the power supply outputs on the ZCU102
If used improperly, it can seriously damage your ZCU102
Before making any adjustments not specifically covered in this
presentation:
– Understand the power requirements for Zynq UltraScale+ MPSoC devices
– Understand the consequences of the change you are making
– Understand that the PMBus devices can ONLY be programmed 4 times
Page 3
Caution!

Xilinx ZCU102 Specifications

General

Processor	Quad-core ARM Cortex-A53, Dual-core ARM Cortex-R5
SD Card	MicroSD card slot
Video Outputs	DisplayPort
FPGA	Xilinx Zynq UltraScale+ XCZU9EG-2FFVB1156E
Memory	4GB DDR4 Component Memory
Storage	MicroSD card slot
Ethernet	Gigabit Ethernet
USB	1 x USB 3.0, 1 x USB 2.0
PCIe	PCIe Gen2 x4
Display	DisplayPort
Power Supply	12V DC input
SATA	SATA 3.0
Clocking	Programmable clocks
Operating System Support	PetaLinux
