6.8 COMPONENTS OF THE ELECTRICAL SYSTEM
1. Shore power plug
2. Batteries
3. Main switch and high-current fuses
4. Shore power distribution board
5. Main switch panel
6. Bow thruster battery and
high-current fuse panel
230 V socket
12V DC outlet 1
6.9
1
6
1
4
2
5
3
