8.2 WATER SYSTEM
The boat is equipped with a pressure water system.The
freshwater system consists of an inlet pipe for the water
tank, a fresh water tank, filter, pump, hydraulic accumula-
torand hot-water tank, a water supply point for the galley
and toilet and a shower.
The tank is located in the technical space under the
helmsman’s position.The filter, pump and hydraulic accu-
mulator are positioned right next to the tank.
The fresh water tank is filled via the inlet pipe (1) located
on the side deck on the boat’s STB side.The pipe is
marked with the text “Water”. The fresh water pump (3)
must be switched on when using the system.The pump
switch (Pentry pump) is positioned on the switch panel
in the corridor. Do not forget to check the pump filter (4)
regularly. In connection with the pump there is a hydraulic
accumulator (2) which automatically keeps working
pressure in the system when the system pump is on.
1
2
3
4
