Xprinter XP-470 Series - Printer Front View; Printer Rear View

2.3 Printer Parts
2.3.1 Front View
Clear Window
Top Cover
LED Indicator
Feed Button
Label Opening
Top Cover Open Lever
Backing Paper Opening
Front Panel
2.3.2 Rear View
1. Ethernet Interface
2. SD Card
3. USB Interface
4. RS-232C DB-9 Interface
5. Power Switch
6. Rear Label Guide
7. Power Jack
2
3
4
5
Note: The interface picture here is for reference only. Please refer to the product specification for
the interfaces availability.
5
7
1
6
