Xray SCX User Manual

OPTION
BEFORE RACING, follow these steps to properly break in the differential.
Loosen the adjustment screw 1/2 turn (180° CCW).
2.0mm
2.0mm
2.0mm
(180° CCW)
½
LOOSEN THE ADJUSTMENT SCREW
FULLY TIGHTEN
FULLY TIGHTEN
LOOSEN THE ADJUSTMENT SCREW 1/8 TURN (45˚CCW).
2.0mm
LOOSEN THE ADJUSTMENT SCREW
(45˚CCW)
HOLD THE LEFT
REAR WHEEL
HOLD THE SPUR GEAR
ROTATE THE WHEEL IN THE
DIRECTION OF TRAVEL
TABLE
2x
BALL DIFFERENTIAL IS NOW READY
10
BALL DIFF BREAK-IN & SET-UP INFO
