Xray SCX User Manual

2. REAR TRANSMISSION
11
323019 COMPOSITE FRONT MOTOR GEAR BOX - LCG - SET
324016 ALU MOTOR PLATE - LCG - SWISS 7075 T6 (3MM)
324052 COMPOSITE GEAR COVER - LCG
324113 ALU 3-PAD TOP SHAFT 20T - LCG - SWISS 7075 T6 - HARD COATED
324120 ALU 3-PAD SLIPPER CLUTCH PLATE - SWISS 7075 T6
324128 ALU 3-PAD SLIPPER CLUTCH PLATE WITH ADAPTER - LCG
324172 COMPOSITE ADJUSTMENT BALL-BEARING HUB (2)
324190 ALU 3-PAD SLIPPER CLUTCH SHIM
324238 COMPOSITE GEAR 38T - LCG - GRAPHITE
364131 SLIPPER CLUTCH PAD SLS - SOFT (3)
364140 ALU 3-PAD SLIPPER CLUTCH PLATE DISC - 7075 T6
364180 SLIPPER CLUTCH SPRING C=30 - BLACK
365878 COMPOSITE 3-PAD SLIPPER CLUTCH SPUR GEAR 78T / 48
BAG
902305 HEX SCREW SH M3x5 (10)
902310 HEX SCREW SH M3x10 (10)
902312 HEX SCREW SH M3x12 (10)
903308 HEX SCREW SFH M3x8 (10)
930308 BALL-BEARING 3x8x4 STEEL SEALED - OIL (2)
940510 BALL-BEARING 5x10x4 RUBBER SEALED - OIL (2)
940612 BALL-BEARING 6x12x4 RUBBER SEALED - OIL (2)
960040 NUT M4 (10)
980320 PIN 3x20 (10)
324902 GEAR DIFFERENTIAL - LCG - SET
#324101
SLIPPER ELIMINATOR - SET
(69T / 48 SPUR GEAR)
#325872
SLIPPER ELIMINATOR
SPUR GEAR 72T / 48
324172
323019
#323019-G
FRONT MOTOR GEAR BOX - LCG - GRAPHITE
SLIPPER CLUTCH SPUR GEARS
#365875 75T / 48 OPTION
#365878 78T / 48 INCLUDED
#365881 81T / 48 OPTION
#980320-T
Titan Pin 3x20 (2)
#324102
SOLID AXLE - LCG - LIGHTWEIGHT - SET
2-PAD SLIPPER
#324114 ALU 2-PAD TOP SHAFT 20T
#324126 ALU 2-PAD SLIPPER CLUTCH PLATE - SHORT
#324129 ALU 2-PAD SLIPPER CLUTCH PLATE - LCG
#364181 SLIPPER CLUTCH SPRING C=45 - BLACK
#324191 STEEL SLIPPER CLUTCH NUT
324017
GRAPHITE MOTOR PLATE - LCG - 3.0MM
960040
364180
364131
364131
364131
940510
940612
930308
930308
324016
324172
324902
324052
324190
324120
324238
364140
980320
365878
324128
324113
902310
323019
323019
902312
902305
903308
