Xray T4'21 User Manual

6
1. GEAR DIFFERENTIAL & FRONT SOLID AXLE
Use tweezers to
insert pin.
981210
P 2x10
981210
P 2x10
972050
O 5x2
972050
O 5x2
964050
S 5x15x0.3
964050
S 5x15x0.3
➊
➋
➌
➍
➍
➍
➎
➎
➊
➋
➌
➍
➎
DETAIL
➎
STEP
STEP DETAIL
304900 XRAY GEAR DIFFERENTIAL - SET
304910 COMPOSITE GEAR DIFF. CASE & COVER
304930 COMPOSITE GEAR DIFF BEVEL & SATELLITE GEARS (2+4)
304970 ALU GEAR DIFF OUTDRIVE ADAPTER - 7075 T6 (2)
304980 COMPOSITE GEAR DIFF CROSS PIN
304990 DIFF GASKET (4)
305134 STEEL SOLID AXLE DRIVESHAFT ADAPTER - HUDY SPRING STEEL™ (2)
305188 COMPOSITE SOLID AXLE 38T - SET
902310 HEX SCREW SH M3x10 (10)
903256 HEX SCREW SFH M2.5x6 (10)
941015 BALL-BEARING 10x15x4 RUBBER SEALED - OIL (2)
964031 WASHER S 3.5x10x0.2 (10)
964050 WASHER S 5x15x0.3 (10)
971240 SILICONE O-RING 24x0.7 (10)
972050 SILICONE O-RING 5x2 (10)
981210 PIN 2x10 (10)
GEAR DIFFERENTIAL
➍
NOTE
ORIENTATION
#304971
HUDY SPRING STEEL™ OUTDRIVES
#304971
HUDY SPRING STEEL™ OUTDRIVES
BAG
304970
304910
964050
972050
304990
304910
903256
981210
981210
304970
941015
971240
972050
964031
304980
304930
304930
941015
#305137
STEEL LIGHTWEIGHT SOLID AXLE DRIVESHAFT
ADAPTERS HUDY SPRING STEEL™
#305136
ALU SOLID DRIVESHAFT ADAPTERS
305188
941015
941015
305134
902310
305134
305188
902310
COMPOSITE SOLID AXLE
CUTAWAY VIEW
#304932
GRAPHITE GEAR DIFF BEVEL & SATELLITE GEARS (2+4)
#304932
GRAPHITE GEAR DIFF BEVEL & SATELLITE GEARS (2+4)
DETAIL
#309002
SET OF CERAMIC BALL-BEARINGS (14)
