26
VIDEO TECH TIP
▶
CHASSIS FLEX ADJUSTMENT
5. FINAL ASSEMBLY
SOFT (NO BRACES)
Recommended for low- to medium-traction
carpet, and asphalt. Generates more
mechanical grip.
MEDIUM
Braces installed, attached at middle & rear
only. This setting is a good compromise
between mechanical grip and steering
response. Ideal for most conditions.
MEDIUM-STIFF
Braces installed, attached at middle-front,
middle, and rear. This setting is recommended
for medium-high to high traction conditions.
STIFF
Braces installed, attached at all positions.
This is the stiffest, most stable setting.
Recommended for high-traction carpet
(such as US black carpet). The car will have
less roll but will also have less overall grip.
CHASSIS FLEX ADJUSTMENT
MEDIUM/MEDIUM-STIFF/STIFF
DO NOT tighten rear nuts fully as it may result in
chassis tweak.
Tighten Gently
(INITIAL SETTING)
960030
N M3
903306
SFH M3x6
902306
SH M3x6
902310
SH M3x10
3x6mm
3x6mm
3x6mm
3x10mm
To Next Page
