29
Fibre Tape
(HUDY #107870)
(NOT INCLUDED)
5. FINAL ASSEMBLY
375390
ALU SCH M3x8
951851
BB 1/8“x5/16“x9/64“
960030
N M3
Rear Wheels & Tires
(NOT INCLUDED)
Bearing Oil
(HUDY #106230)
Gently tighten the wheel nuts
so the wheel turns freely, but
without excessive axial play.
4x
Front Wheels & Tires
(NOT INCLUDED)
The shim behind the wheel bearing
affects the front track-width.
WIDER TRACK-WIDTH
Easier to drive, less steering, less
responsive.
NARROWER TRACK-WIDTH
More steering, more responsive, but
more difficult to drive.
FRONT TRACK-WIDTH
372290
SHIM 3.2x4.8x0.5
To Next Page
