903308
SFH M3x8
VIDEO TECH TIP
▶
BATTERY MOUNTING
SYSTEM
902320
SH M3x20
901305
SB M3x5
Double-sided Tape
HUDY #107875
(NOT INCLUDED)
Receiver
(NOT INCLUDED)
Speed Controller
(NOT INCLUDED)
Feed the receiver wire
into the antenna tube.
NOTE: If the antenna tube does not hold the antenna
properly, apply a small drop of the CA glue to the
outside end of the antenna tube while inserting it
into the holder. Make sure not to apply glue to the
inside of the antenna tube, or the antenna wire will
get permanently stuck.
CA
7. FINAL ASSEMBLY
NOTE ORIENTATION
To ensure correct functioning of the battery
holder, do not overtighten the screw; the holder
must be able to move.
HEIGHT ADJUSTMENT
1 turn = 0.5mm
