Xray XB8 Series User Manual

27
ROLL CENTER
903308
SFH M3x8
903312
SFH M3x12
XB8XB8E
4x12mm
3x12mm
3x10mm
3x12mm
3x12mm
NOTE
ORIENTATION
M3
M4
Check for free
movement
After the top deck assembly check for free movement of steering system.
7. STEERING
902312
SH M3x12
902310
SH M3x10
960030
N M3
All possible mounting
alternatives of eccentric bushings
RIGHT THREAD
RIGHT THREAD
LEFT THREAD
LEFT THREAD
28 mm
28 mm
LEFT THREAD LEFT THREAD
RIGHT THREAD RIGHT THREAD
NOTE
ORIENTATION
NOTE
ORIENTATION
NOTE
ORIENTATION
NOTE
ORIENTATION
NOTE
ORIENTATION
NOTE
ORIENTATION
DETAIL
DETAIL
DETAIL
NOTE ORIENTATION
INITIAL SETTING
903412
SFH M4x12
960040
N M4
BOOK
SET-UP
903310
SFH M3x10
DO NOT OVERTIGHTEN SCREWS
Install the pivot balls with Professional
Multi Tool (HUDY #183011)
0.5º1º

Xray XB8 Series Specifications

General

Scale	1/8
Drive	4WD
Type	Buggy
Chassis	7075 T6 Aluminum
Body	Not included
