Xray XB8 Series User Manual

28
ROLL CENTER
CASTER
ACKERMANN
BUMP STEER
TOE-IN
XB8XB8E
L=R
2x
NOTE ORIENTATION
Adjustment block towards outside
Check for free
movement
Check for free
movement
INITIAL SETTING
NOTE ORIENTATION
Adjustment block towards outside
7. STEERING
All possible mounting
alternatives of eccentric bushings
2.0mm
1.0mm
1.0mm
UPPER CLIP
LOWER SHIM
Behind arm
Behind arm
960030
N M3
902310
SH M3x10
INITIAL SETTING
CASTER
CASTER
UPPER CLIP
(Behind arm)
LOWER SHIM (Behind arm)
4mm 2mm
4mm 24º 21º
3mm 25.5º 22.5º
2mm 27º 24º
1mm 28.5º 25.5º
0 30º 27º
NOTE
ORIENTATION
BOOK
SET-UP
BOOK
SET-UP
908312
SCH M3x12
0.5º1º

Xray XB8 Series Specifications

General

Scale	1/8
Drive	4WD
Type	Buggy
Chassis	7075 T6 Aluminum
Body	Not included
