Xray XB8 Series User Manual

40
10. RADIO CASE
XB8E
902312
SH M3x12
902308
SH M3x8
902308
SH M3x8
907206
2x6
If the receiver box has 2 different-size openings
for cable entry (narrow and wider), cut away
the tab for the appropriate opening to allow the
cables to fit properly.
Receiver
(NOT INCLUDED)
Antenna
Servo Screw
(NOT INCLUDED)

Xray XB8 Series Specifications

General

Scale	1/8
Drive	4WD
Type	Buggy
Chassis	7075 T6 Aluminum
Body	Not included
