Xray XB8 Series User Manual

54
SHOCK ABSORBERS
SHOCK ABSORBERS
XB8E
960030
N M3
902319
SH M3x18
LEFT thread
902318
M3x18
FRONT SHOCKS (SHORT)
NOTE ORIENTATION
SHORTER
LONGER
On the front right arm use the SILVER M3x18
screw - this screw has LEFT THREAD
Use STANDARD
M3x18 screw
3x18mm
L=R
2x
902319
SH M3x18
LEFT thread
960030
N M3
902318
SH M3x18
REAR SHOCKS (LONG)
On the rear left arm use the SILVER M3x18
screw - this screw has LEFT THREAD
Use STANDARD
M3x18 screw
M3x18mm
NOTE ORIENTATION
SHORTER
LONGER
L=R
DETAIL
INITIAL SETTING
L=R
INITIAL SETTING
DETAIL
L=R
2x
DETAIL
L=R
INITIAL SETTING
BOOK
SET-UP
BOOK
SET-UP
12. FINAL ASSEMBLY
INITIAL SETTING
DETAIL
