19
4.
REAR
SUSPENSION
353354-H
SHIM 3x9x7
902318
SH M3x18
902330
SH M3x30
960030
N M3
2x
L=R
7mm
NOTE
ORIENT
ATION
INITIAL SETTING
INITIAL SETTING
DETAIL
L=R
960030
N M3
903312
SFH M3x12
902314
SH M3x14
3x18mm
3x30mm
908318
SCH M3x18
18
20
Table of Contents
Tools Required
4
Equipment Required
4
Equipment Included
5
Center Differential
8
Front Transmission
10
Rear Transmission
12
Rear Suspension
14
Front Suspension
20
Front & Rear Assembly
25
Final Assembly
44
Throttle Linkage Adjustment
48
Troubleshooting Guide
48
Diff Maintenance
49
Maintenance
55
