30
ROLL CENTER
CASTER
ACKERMANN
BUMP STEER
TOE-IN
L=R
2x
NOTE ORIENTATION
Adjustment block towards outside.
Check for free
movement.
Check for free
movement.
INITIAL SETTING
NOTE ORIENTATION
Adjustment block towards outside.
7. STEERING
All possible mounting
alternatives of eccentric bushings.
2mm
1+1mm
2mm
1mm
1mm
UPPER CLIP
LOWER SHIM
Behind arm
Behind arm
960030
N M3
902310
SH M3x10
CASTER
CASTER
UPPER CLIP
(Behind arm)
LOWER SHIM (Behind arm)
2mm
4mm 21º
3mm 22.5º
2mm 24º
1mm 25.5º
0 27º
LOGO XRAY
ORIENTATION
FRONT
BOOK
SET-UP
BOOK
SET-UP
908312
SCH M3x12
INITIAL SETTING
0.5º1º
