Page #53 background imageLoading...
Page #53 background image
53
909395
SS 3.5x45
901303
SB M3x3
901303
SB M3x3
901305
SB M3x5
902318
SH M3x18
903308
SFH M3x8
1.5~2.5mm
STEP DETAIL
➍
DETAIL
FRONT C-HUB SUSPENSION
DETAIL
17.5mm
L=R
908312
SCH M3x12
➊
➋
➌
➌
➍
➎
3x3mm
3x5mm
3x8mm
3x18mm
INITIAL SETTING
0.5º1º
For bumper assembly, follow page 26 / step 3
