Xray XT4 User Manual

22
CAMBER
ROLL CENTER
WHEELBASE
4. REAR TRANSMISSION
3x6x2mm
S 2.5
S 2.5
TIGHTEN
GENTLY
TIGHTEN
GENTLY
Check for free
movement
DETAIL
59mm
2x
L=R
8mm THREAD
8mm THREAD
THREAD
THREAD
Install the pivot balls with Professional
Multi Tool (HUDY #183011)
362280
CON. SHIM 3x6x2
L=R
DETAIL
INITIAL SETTING
L=R
DETAIL
INITIAL SETTING
CONICAL SHIM
3x6x2mm
ALU CONICAL SHIMS
#362280 SILVER INCLUDED
#362280-K BLACK OPTION
#362280-O ORANGE OPTION
2x
L=R
NOTE ORIENTATION
961025
S 2.5
962031
S 3x6x0.1
962030
S 3x6x0.3
902254
SH M2.5x4
306219
SHIM 3x6x2
3x6x0.1mm
3x6x0.3mm
Use 0.1mm or 0.3mm shim
to adjust the play.
Adjustment Shim BEHIND HUB moves
hub forward.
SHORTER WHEELBASE
ARM
Adjustment Shim IN FRONT OF HUB
moves hub rearward.
LONGER WHEELBASE (INITIAL SETTING)
ARM
2x
2x
L=R
L=R
NOTE
ORIENTATION
NOTE
ORIENTATION
960030
N M3
902310
SH M3x10

Xray XT4 Specifications

General

Category	Motorized Toy Car
Scale	1/10
Suspension	Independent
Drive System	4WD
Shock Type	Oil-filled
