53
10. ELECTRONICS
(Brick Alernative)
902314
SH M3x14
903412
SFH M4x12
903410
SFH M4x10
960030
N M3
960040
N M4
XT8E
ALETRNATIVE 1
(INITIAL SETTING)
Speed Controller
(NOT INCLUDED)
Double-Sided Tape
HUDY #107875
(NOT INCLUDED)
Cut Battery Plate
View
Cut the foam as needed to fill in space between
the batteries and holder.
Battery
(NOT INCLUDED)
Velcro Battery Strap
ALETRNATIVE 2

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xray XT8 and is the answer not in the manual?

Xray XT8 Specifications

General IconGeneral
Scale1/8
4WD/2WD4WD
Width300 mm
Chassis MaterialAluminum
Shock TypeOil-filled
Height180mm
Gear TypeSpur Gear
