Xray XT8 User Manual

54
XT8
902312
SH M3x12
10. RADIO CASE
10
BAG
302611 ADJ. TURNBUCKLE L/R 35 MM - HUDY SPRING STEEL™ (2)
352460 PIVOT BALL 5.8 (10)
352670 SERVO BALL JOINT 5.8MM (4)
356003 COMPOSITE RADIO CASE SET - HARD
356050 BATTERY CABLE WITH SWITCH (OPTION)
356120 STEERING SERVO MOUNT - SET
356200 BRAKE/THROTTLE ARMS & STEERING SERVO ARMS - SET
356219 COMPOSITE SERVO SHIMS 1.0, 1.5 & 2.5MM (2+2+2)
389135 CONNECTING CABLE RECEIVER/BATT. PACK (OPTION)
LEFT THREAD
RIGHT THREAD
Use appropriate servo arm:
K - (23T)
H - (24T)
F - (25T)
902306 HEX SCREW SH M3x6 (10) (OPTION)
902310 HEX SCREW SH M3x10 (10)
902312 HEX SCREW SH M3x12 (10)
902314 HEX SCREW SH M3x14 (10)
903412 HEX SCREW SFH M4x12 (10)
960030 NUT M3 (10)
961032 WASHER S 3.2 (10)
306310 ANTENNA TUBE (2)
The length of the linkages varies according to the type of servo.
approx. 19.5mm
DETAIL
NOTE
ORIENTATION
Receiver battery
(NOT INCLUDED)
306310
356003
356003
902310
902312
902310
902306
(NOT INCLUDED)
356003
356003
356003
903412
903412
902314
356219
356120
902314
356120
356219
Throttle Servo
(NOT INCLUDED)
Steering Servo
(NOT INCLUDED)
Servo Screw
(NOT INCLUDED)
Receiver
(NOT INCLUDED)
356200
960030
352670
352460
352460
902314
902312
302611
Personal transponder
(NOT INCLUDED)
Install the pivot balls with Professional
Multi-Tool (HUDY #183011).
CLAMP ALU SERVO HORNS
#293407 23T OPTION
#293408 24T OPTION
#293409 25T OPTION
ALU SERVO HORNS
#293501 23T OPTION
#293502 24T OPTION
#293503 25T OPTION
961032
961032

Xray XT8 Specifications

General

Scale	1/8
4WD/2WD	4WD
Width	300 mm
Chassis Material	Aluminum
Shock Type	Oil-filled
Height	180mm
Gear Type	Spur Gear
