Xray XT8 User Manual

61
XT8
SHOCK ABSORBERS
SHOCK ABSORBERS
901303
SB M3x3
902310
SH M3x10
903314
SFH M3x14
960030
N M3
902319
SH M3x18
LEFT thread
902318
M3x18
FRONT SHOCKS (SHORT)
NOTE ORIENTATION
SHORTER
LONGER
On the front right arm use the SILVER M3x18
screw - this screw has LEFT THREAD.
Use STANDARD
M3x18 screw
3x18mm
L=R
2x
902319
SH M3x18
LEFT thread
960030
N M3
902318
SH M3x18
12. FINAL ASSEMBLY
REAR SHOCKS (LONG)
On the rear left arm use the SILVER M3x18
screw - this screw has LEFT THREAD.
Use STANDARD
M3x18 screw
M3x18mm
NOTE ORIENTATION
SHORTER
LONGER
L=R
INITIAL SETTING
DETAIL
L=R
2x
Brake rod
Throttle rod
Thread brake rods into plastic
pivots until flush with outer end.
Brake rod
Cut off
remaining
material
Use servo horn to match your servo
K - (23T) H - (24T) F - (25T)
INITIAL SETTING
DETAIL
L=R
BOOK
SET-UP
BOOK
SET-UP
DETAIL
L=R
INITIAL SETTING
DETAIL
INITIAL SETTING
L=R
CLAMP ALU SERVO HORNS
#293444 23T OPTION
#293445 24T OPTION
#293446 25T OPTION
#293447 23T OPTION
#293448 24T OPTION
#293449 25T OPTION
ALU SERVO HORNS
#293504 23T OPTION
#293505 24T OPTION
#293506 25T OPTION
#293507 23T OPTION
#293508 24T OPTION
#293509 25T OPTION
Tighten screw until snug.
Pivots should move freely.
Small gap
Small gap
DETAIL
