MIDI Control
XTONE Pro has 6 smart foot switches and 1 expression pedal interface for playing control. When you press them, Pro sends MIDI CC commands out via the
USB and MIDI OUT interface. When a valid MIDI command is received on the MIDI IN interface, Pro will also forward it to the USB and MIDI OUT interface in
real time.
The expression pedal recommended ZOOM FP02M.
Nowadays, software effects have very powerful MIDI control systems. With Pro’s foot switches and expression pedal, you can do whatever control you want.
For details, read the MIDI specification chapter below.
MIDI Command Group
XTONE Pro has three MIDI command groups, each group corresponds to 7 different value of MIDI CC commands.
Long press A, B, C foot switch can be switched to the corresponding group, different groups show different LED colors:
A group - green; B group - blue; C group
- red.
Different MIDI command groups, 6 foot switches + 1 expression pedal can send 7 different MIDI commands, which means XTONE Pro can send 3 x 7 = 21
different MIDI commands, control 21 different parameters in the software.
The following lists the MIDI CC values corresponding to the foot switch and expression pedal in the three MIDI command groups.
A group - green
B group - blue
C group - red
FS A
CC 10
FS A
CC 40
FS A
CC 70
FS B
CC 22
FS B
CC 42
FS B
CC 71
FS C
CC 11
FS C
CC 43
FS C
CC 72
FS D
CC 24
FS D
CC 64
FS D
CC 73
FS E
CC 25
FS E
CC 15
FS E
CC 74
FS F
CC 26
FS F
CC 41
FS F
CC 75
EXP
CC 7
EXP
CC 4
EXP
CC 1
