xsto SCL170A - Description; The Structure; Technical Data; Application

5
2 Description
2.1 The structure
1: Top Cover 2:Sensor 3: Loading Board Support 4: Solid Tire 5:
Rotating Support Leg 6: Directional Wheel 7: Control Panel 8:
8:Emergency stop switch 9:Control Handle 10:Wire Handle Controller 11:
Ball Screw Shaft 12: Portable Lithium Battery 13: Motor Shell 14: Climbing
S Arm 15: Aluminum Alloy Loading Board
2.2 Technical Data
This manual is suitable for SCL170A series ONLY.
2.3 Application
15
10
3
5
7
2
8
11
12
13
1
4
9
14
6
