XSY AT2 - Page 15

P48
6th descent velocity
1---1000
50 Hz/S
P49
7th descent velocity
1---1000
50 Hz/S
P50
Multi function input 1
(X1 binding post)
0: invalid, terminal is non-
functioning
1: wire control stop
2: keying stop;
3: keying operation;
4: stop keying;
5: wire forward operation
6: wire reverse operation;
7: reservation
8: error reset signal;
9: wire reversing switch;
10: keying forward switching;
13
13页
10: keying forward switching;
11: keying forward switching;
12: reverse switch keying;
13: section speed input 1;
14: section speed input 2;
15: section speed input 3;
16: external error signal.
P51
Multi function input 2 Idem
14
P52
Multi function input 3 Idem
15
P53
Multi function input 4 Idem
5
P54
Multi function input 5 Idem
6
P55
Multi function input 6 Idem
9
