FB160 Folding Bike
FB160 Assembly Part Checklist
No. 01/02
Main Frame
(1pc)
No. 03
Seat Support Tube
(1pc)
No. 04/08
Handlebar Tube/Console
(1pc / 1pc)
No. 05
Front Stabilizer
(1pc)
No. 09L/R
Pedal (L/R)
(1pc/1pc)
No. 06
Rear Stabilizer
(1pc)
No. 07
Seat
(1pc)
No. 10
Club Knob
(1pc)
No. 73
Hex Head Wrench
(1pc/1pc)
No. 72
Allen Key
(1pc)
Note: Above parts are all needed to assemble this machine. Before you start to assemble, please check the hardware
packing to make sure they are included.
Some of the parts for this machine are preassembled on the unit. Please read your manual to ensure everything is
there.
