Xterra FB160 User Manual

FB160 Folding Bike
5
1. Pull out the Lock Pin (No. 11) from the Front Support Tube (No. 01) and
adjust the Front Support Tube (No. 01) to the open position then re-insert the
Lock Pin (No. 11) to secure the frame position.
2. Attach the Front Stabilizer (has wheels) (No. 05) to the Front Support Tube
(No. 01), tighten with the pre-installed 2 Curved Washers (No.13) and 2
Domed Nuts (No. 14).
3. Repeat the procedure for the Rear Stabilizer (No. 06).
FB160 Assembly Instructions
02
11
14
13
05
14
13
06
01
11
11
73 Wrench
Front Stabilizer and Rear Stabilizer
1

Xterra FB160 Specifications

General

Brand	Xterra
Model	FB160
Category	Exercise Bike
Language	English
