Xterra TR3.0 - Treadmill Assembly; Assembly Pack Checklist

TR3.0 Treadmill
5
#100. Ø5/16” x Ø18 x 1.5T
Flat Washer
(8 pcs)
#99. 5/16” x 1/2”
Hex Head Bolt
(8 pcs)
Hardware Steps 2
Hardware Steps 3 Hardware Steps 4
#125. 5/16” x 3/4”
Button Head Socket
Bolt (4 pcs)
#125. 5/16” x 3/4”
Button Head Socket
Bolt (4 pcs)
#103. M6 L Allen Wrench
Assembly Tools
#102. Combination M5
Allen Wrench & Phillips
Head Screw Driver
TR3.0 Assembly Pack Checklist
#90. 13mm Wrench
#80.M8 x 1.5T
Split Washer
(4 pcs)
