KEY NO.
PART NO.
DESCRIPTION
Q'TY
1
8025001
Main Frame
1
2
8025002
Frame Base
1
3
8025003
Incline Bracket
1
4
8025004
Right Upright
1
5
8025005
Left Upright
1
6
8025006
Console Support
1
7
8025007
Outer Slide
1
8
8025008
Inner Slide
1
9
8025009
Handrail Support
1
10
8025010
Incline Motor
1
11
8025011
Drive Belt
1
12
8025012
Motor Bracket
1
13
8025013
Drive Motor
1
14
8025014
Running Belt
1
15
8025015
Running Deck
1
16
8025016
Front Roller W/Pulley
1
17
8025017
Rear Roller
1
18
8025018
Deck Cross Brace
1
20
8025020
Locking Knob
1
21
8025021
Console Assembly
1
23
8025023
Metal Tube End Cap
4
24
8025024
Handgrip Foam
2
25
8025025
Motor Top Cover
1
26
8025026
Adjustment Base (L)
1
27
8025027
Adjustment Base (R)
1
28
8025028
Speed/Hand Pulse Complex
1
29
8025029
Incline/Hand Pulse Complex
1
30
8025030
Breaker
1
31
8025031
On/Off Switch
1
32
8025032
Ø48 × 18L_Transportation Wheel
4
33
8025033
Handgrip End Cap
2
35
8025035
M8 × Ø30 × 35L_Cushion
6
37
8025037
Foot Rail
2
40
8025040
Motor Cover Anchor(D)
5
43
8025043
□30 × 60_Square End Cap
2
44
8025044
Square Safety Key
1
45
8025045
Power Socket
1
46
8025046
3/8" × 7T_Nut
3
47
8025047
Sensor Rack
1
48
8025048
Power Cord
1
49
8025049
300m/m_Connecting Wire (White)
1
50
8025050
300m/m_Connecting Wire (Black)
1
51
8025051
100m/m_Connecting Wire (Black)
1
52
8025052
Motor Controller
1
PARTS LIST
