Xterra TRX2500 - Page 8

7
Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018
Email: customerservice@dyaco.ca
ASSEMBLY PACK CHECKLIST
# 102. Combination M5 Allen Wrench &
Phillips Head Screwdriver (1pc)
# 103. M6 (66 × 86)
L Allen Wrench (1pc)
# 125. 5/16" ×3/4"
Button Head Socket Bolt (8pcs)
# 80. Ø8 × 1.5T
Split Washer (4pcs)
# 44. Square Safety Key (1pc)
# 104. Lubricant (1pc)
# 99. 5/16" ×1/2"
Hex Head Bolt (8pcs)
# 90. 13L_Wrench (1pc)
# 100. Ø5/16" × Ø18 × 1.5T
Flat Washer (8pcs)
