15
Error Message
E1 (ERROR 1):
Normal state: During workout, when the monitor did not get the count signal from the gear
motor more than 4 seconds and check under successive 3 times then the LCD
will show E1.
Power on state: The gear motor will return to zero automatically, when the signal of motor
cannot be detected for more than 4 seconds then the gear motor’s driver will be
cut off immediately and show the E1 on the LCD display. All the other digital
and function mark are blank, and the output signals are cut off also.
E2 (ERROR 2):
When the monitor read the memory data, if the I.D. code is not correct or the memory IC
damages then the monitor will show E2 immediately at power on.
E3 (ERROR 3):
After 4 seconds by start mode, the computer detects the faulty motor did not leave the zero
point then the LCD bar displays “E3”.
Technical data of the current adapter
1. Output: DC 6~9V/0.5~1A
